Proven Platform with Military Lineage

The Bell 407GXi: Proven. Trusted. Advanced.

Two military helicopters fly over a dry, mountainous landscape, surrounded by sparse vegetation.

Proven Platform for Your Missions

Bell maintains a long-standing relationship with Chile in providing world-class helicopters and industry-leading support. It would be an honor to continue supporting The Chilean Air Force’s missions.

It is certainly a multi-role helicopter but from a pilot's perspective it's a very capable ship. It's very fast it has plenty of power.
407GXi Pilot
Orange County Florida Sheriff's Office

Proven Platform for Your Missions

The latest Bell 407GXi platform showcases Bell’s commitment to safety displayed in the overarching design philosophy that Bell incorporates into its products design and manufacturing process. Bell understands the need for large safety margins that begin with each aircraft component design. That is why bell aircraft have a reputation for high quality components with proven field reliability. And why the Bell single-engine helicopters have demonstrated some of the highest operational readiness rate of any other rotary wing airframe in the US military inventory.

Battlefield Tested

The 407 design benefits from Bell’s long history of designing, building, and supporting military helicopters for different US military branches. For example, the Bell 407GXi Transmission system is derived from the popular Bell OH-58D Kiowa Warrior Helicopter flown by the United States Army. Its 4-bladed main rotor system, its intuitive cockpit, and responsive controls, provide an extremely high level of maneuverability and stability that make the 407 a superior platform from the piloting perspective.

Advanced Capabilities

The M250-C47E/4 engine with Dual Channel FADEC is equipped with redundant sensors and has a manual back up mode which provides the pilot direct control of engine power via the throttle on the collective. The Dual Channel FADEC reverts directly to manual mode for any FADEC system critical fault, including complete loss of electrical power.

A police helicopter hovers above a busy highway in an urban area with buildings and billboards.

Ready to Continue Serving Your Missions

The Chilean Air Force has operated the Bell 206, 412 and UH-1H “Huey” for years. Bell’s commitment to proven and durable products paired with industry-leading support remains unwavering – now and in the future.

Prioritizing Operational Readiness

Bell continues to focus on customer support. Our global customer solutions in Chile include two Customer Service Facilities: EagleCopters and ENAER. Both facilities are part of a global support network that focuses on priority 1: Operational Readiness.

Our Public Safety Product Solutions

Explore our public safety solutions and to hear more from our customers.

Public Safety
A helicopter spraying chemicals flies over a forested landscape. Smoke trails descend below.

Bell 407 Specifications

Select a document
Bell 407GXi Fact Sheet
Bell 407GXi Product Specifications
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Performance
Hover Ceiling IGE
13,550ft
Hover Ceiling OGE
11,940ft
Max Cruise
133 kts | 246 km/h
Range at VLRC
337 nm | 624 km
Max Endurance
4.0 hrs

*Std Max GW, ISA, Std. fuel - no reserve, at sea level

Capacities
Standard Seating
1+6
Standard Fuel
127.8 US gal / 482.8 liters
Aux Fuel
19 US gal / 71.9 liters
Cabin Volume**
85ft3
Aft Baggage Compartment Volume
16 ft3 / 0.5 m3
Empty Weight - (Base 407GXi Aircraft)
2,700 lbs / 1,224 kg
Max Gross Weight (Internal, Standard)
5,000 lbs / 2,268 kg
Max Gross Weight Internal - Optional
5,250lb / 2,381 kg
Max Gross Weight (External Load)
6,000 lbs / 2,722 kg
Useful Load - Internal -Standard - Base 407GXi -Specification
2,300 lbs / 1,043 kg
Useful Load (Internal, Optional, Base 407GXi)
2,550 lbs / 1,156 kg
Cargo Hook Capacity
3,100 lbs / 1,406 kg
Powerplant
Takeoff
862 SHP / 643 kW
Max Continuous
761 SHP / 567 kW

Rolls-Royce Model 250-C47E/4 turboshaft engine with dual digital FADEC.

Avionics

Enhanced pilot awareness with the GARMIN G1000H® NXi integrated Flight Deck with synthetic vision and terrain avoidance warning

  • Wireless connectivity with Flight Stream 510 allows pilots to quickly sync flight plans and upload databases from smart devices
  • Moving map can be displayed on HSI freeing up the MFD for flight planning and other uses
  • Multi-Pane MFD capability for pilot selectable display of 2 simultaneous page views on the MFD
  • Power Situation Indicator (Single Indicator for Quick Pilot Monitoring)
  • Fuel Flow Indication and Range Ring mapping
  • Tail Rotor Camera (Display on MFD)
  • Additional features and options include: WireAware, ADS-B out and in, Radar Altimeter, TAS/TCAS I Traffic, and XM Weather
